Generac Guardian EGD-5524KIT
Generac Guardian EGD-5524KIT
Hover to zoom
1 Of 5

Generac Guardian 17kW Home Standby Generator System (16-Circuit 100A ATS) Alum Enclosure

Model:

EGD-5524KIT

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Generac Guardian 17kW Home Standby Generator System (16-Circuit 100A ATS) Alum Enclosure
Generac Guardian 17kW Home Standby Generator System (16-Circuit 100A ATS) Alum Enclosure
Model: EGD-5524KIT
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Electric Generators Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Emergency

Style

Standby (Air Cooled)

Run Watts

17,000 Rated Watts

Voltage

120/240 Single-Phase

Fuel

LP/Natural Gas

Engine

Generac OHVI

  • Fully Automatic Operation (Generator Model# 5524)
  • Generac OHVI Air-Cooled Engine
  • Maximizes engine "breathing" for increased fuel efficiency
  • Operates on clean burning, efficient Natural Gas or LP (Vapor)
  • Whisper-Test™ low speed exercise mode
  • Sound level comparable to an idling car
  • Reduces sound level from 66 to 60 d(B)A during weekly exercise
  • Weather Protected Aluminum Enclosure
  • Shelters generator from weather and reduces exterior noise
  • Two Line LCD Digital Controller
  • Allows for simple user interface for ease of operation
  • Automatic Shutdown
  • High coolant temp, low coolant, low oil pressure and overspeed
  • Built-in Battery Charger (Battery Sold Separately)
  • Keeps your battery charged 24/7/365
  • Includes 16 circuit load center style auto transfer switch (100A)
  • 5' Pre-wired external connection box from wall to generator
  • 30' Pre-wired indoor conduit from switch to external box
  • 2' Pre-wired indoor conduit from transfer switch to main panel
  • Composite mounting pad and 1' flexible fuel line connector

Specifications

EGD-5524KIT
specs product image PID-7749
Overview
Weight
451 Pounds
Made in USA
Yes
Consumer Warranty
3 Years
Commercial Warranty
3 Years
Product Style
Standby Generator
Product Length
48 Inches
Product Width
25 Inches
Product Height
29 Inches
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
17000 Watts
Surge Watts
17000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
16000 Watts
LP Power Capacity
17000 Watts
NG Fuel Consumption @ 50% Load
183 ft³/hr
LP Fuel Consumption @ 50% Load
1.61 gallons/hr
Rated Amps
71 Amps
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
66 dbA
Transfer Switch
Automatic (Included)
Transfer Switch Amperage
100-Amps
Battery
Not Included (525 CCA)
Enclosure
Aluminum
A/C Ton Rating
5-Tons
Mounting Pad
Composite (Included)
Transfer Switch Style
Pre-Wired (16-Circuit)
ATS Load Shedding
Not Compatible
ATS Poles
2 Poles
ATS Service Disconnect
No
Cooling System
Air Cooled
Grade Type
Emergency
Engine
Engine Brand
Generac OHVI
CC
992 CC
Consumer Engine Warranty
3 Years
Commercial Engine Warranty
3 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Transfer Switch Circuits
15A 120V
5
20A 120V
5
20A 240V
1
40A 240V
1
50A 240V
1
