Champion 73536i - 1700 Watt Inverter Generator w/ Parallel Capability (CARB)

Model:

73536I

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
Champion 73536i - 1700 Watt Inverter Generator w/ Parallel Capability (CARB)
Champion 73536i - 1700 Watt Inverter Generator w/ Parallel Capability (CARB)
Model: 73536I
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Electric Generators Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Recreational

Style

Portable

Run Watts

1,700 Rated Watts

Surge Watts

2,000
Starting Watts

Fuel

Gasoline

Engine

Champion



Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
  • Champion Inverter Technology
  • Clean, quiet power for campsites, RV's, cabins & tailgating
  • 2000 Max Rated Starting Watts
  • Easily power a small appliance or a couple household items
  • Champion 80cc OHV Engine w/ Low Oil Sensor
  • Provides added protection to extend engine life
  • Economy Mode Switch - 9.5 Hours of Run Time @ 1/4 Load
  • Adjusts engine speed to the optimum level depending on load
  • Quiet - Only 53 dBA at 7M
  • Fully enclosed durable housing reduces sound output
  • Parallel Operation Capability
  • Increase available wattage when linking 2 Champion 73536i gens
  • Stackable Design
  • Great for storage, traveling and when paralleling generators
  • Lightweight Design w/ Built-In Carrying Handle
  • Makes this generator easy to move where you need it most
  • Added Features
  • 12V DC Outlet & USDA-Approved Spark Arrestor/Muffler
  • DC Charging Cable, Oil-Funnel & Spark Plug Socket
  • Engine Oil NOT Included
  • EPA & CARB Compliant
  • 3-Year Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Benzene which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov

Specifications

Plug Types
12-Amp DC
NEMA 5-20R (Wall-Type)
73536I
specs product image PID-15661
Overview
Weight
49 Pounds
Made in USA
No
Consumer Warranty
3 Years
Product Style
Portable Generator
Product Length
19.3 Inches
Product Width
13.2 Inches
Product Height
16.3 Inches
UPC
896682735367
Product Specs
Voltage
120 Single-Phase
Frequency
60 Hertz
Alternator
Inverter
Auto Voltage Regulation
Yes
Rated Watts
1700 Watts
Surge Watts
2000 Watts
Fuel Type
Gasoline
Rated Amps
14 Amps
Tank Size
1 Gallon
Fuel Tank Material
Metal
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
53 dbA
Idle Control
Yes
Grade Type
Recreational
Engine
Engine Brand
Champion
Starting System
Recoil Start
CC
80 CC
Consumer Engine Warranty
3 Years
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Plugs
12-Amp DC
1
NEMA 5-20R - Wall-Type
1
