Cummins Onan 20kW Standby Power Generator (LP)

Model:

20GGMA-6111C

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Cummins Onan 20kW Standby Power Generator (LP)
Cummins Onan 20kW Standby Power Generator (LP)
Model: 20GGMA-6111C
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Electric Generators Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Emergency

Style

Standby (Liquid Cooled)

Run Watts

20,000 Rated Watts

Surge Watts

20,000
Starting Watts

Fuel

LP

Engine

GM

  • Cummins Onan RS Series 20000 Liquid Propane Generator
  • Fully automatic operation when paired w/ a Cummis Onan ATS
  • GM 3.0L 4-Cylinder Liquid-Cooled Engine
  • A powerful, reliable & fuel efficient motor built for long life
  • Operates at 1800 RPM for quiet operation
  • High-Quality Brushless Alternator
  • Provides clean power for even the most sensitive electronics
  • Less than 5% THD from no load to full load & Less than 3% w/ load
  • Heavy-Duty Aluminum Weather-Resistant Housing
  • Corrosion resistant design extends the life of the generator
  • Enclosed Exhaust Silencer
  • Provides quiet output of 66 dB(A) @ 7m (Full Load)
  • Cummins Proprietary Control System
  • Self-diagnostics, gen-set protection and safety features
  • 120V Coolant Heater & Two Easy Access Service Doors
  • Allows for easier starting in freezing conditions
  • Key-lockable design provides added security
  • Listed to UL2200 Engine/Generator Standard for Safety
  • Standard 2-Year Warranty
  • **Please Note - Requires Loading Dock or Forklift For Delivery**
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer, and Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

20GGMA-6111C
specs product image PID-11711
Overview
Weight
1105 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Style
Standby Generator
Product Length
85.3 Inches
Product Width
30 Inches
Product Height
46.7 Inches
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
20000 Watts
Surge Watts
20000 Watts
Fuel Type
LP
LP Power Capacity
20000 Watts
LP Fuel Consumption @ 50% Load
2.2 gallons/hr
LP Fuel Consumption @ 100% Load
3.2 gallons/hr
Rated Amps
83 Amps
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
66 dbA
Transfer Switch
Automatic (Not Included)
Battery
Not Included (525 CCA)
Enclosure
Aluminum
Mounting Pad
Concrete (Not Included)
Cooling System
Liquid Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
GM
CC
3000 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
