Cummins RS100 Quiet Connect™ Series 100kW Standby Power Generator (120/240V Single-Phase)

Model:

A054F867

Write A Review
$36,727.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
This Item Is Built To Order
synchrony card logo
$643 / Month
With our 82 months 10.99% APR*
82 fixed monthly payments required.
Cummins RS100 Quiet Connect™ Series 100kW Standby Power Generator (120/240V Single-Phase)
Cummins RS100 Quiet Connect™ Series 100kW Standby Power Generator (120/240V Single-Phase)
Model: A054F867
$36,727.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Electric Generators Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Emergency

Style

Standby (Liquid Cooled)

Run Watts

100,000 Rated Watts

Voltage

120/240 Single-Phase

Fuel

LP/Natural Gas

Engine

Cummins Onan

    ^Please Note - Requires Loading Dock or Forklift For Delivery^
  • Cummins Quiet Connect
  • Great for home & light commercial applications
  • Powerd By Cummins 5.9L Turbocharged Liquid-Cooled Engine
  • 1800 RPM design provides reliability and fuel efficiency
  • Brushless CA Series Alternator
  • Provides +/- 1% voltage & +/- 0.25% frequency regulation
  • As close to utility power as you can get in a standby generator
  • Advanced Design Sound Attenuated Aluminum Enclosure
  • Aesthetically appealing withstands winds up to 180 MPH
  • One of the quietest generators of its kind (71dB @ 7M)
  • PowerCommand® Electronic Control
  • Provides industry-leading self-diagnostic capabilities
  • Flexible Exercise Mode
  • Exercise at a time, frequency and duration that suits you
  • Reducing unnecessary fuel consumption, emissions and noise
  • Coolant Heater For Extreme Environmental Conditions (Included)
  • Factory installed, Allows for cold weather starts down to -40 °F
  • Automatic Transfer Switch (Sold Separately)
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer, and Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

A054F867
specs product image PID-68377
General Information
Product Category
Generator - Standby
Overview
Product Category
Generator - Standby
Weight
2830 Pounds
CARB Compliant
Yes
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Style
Standby Generator
Product Length
118.7 Inches
Product Width
40.0 Inches
Product Height
58.3 Inches
Additional Model Numbers

C100 N6, A054F867

Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brushless
Rated Watts
100000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
100000 Watts
LP Power Capacity
100000 Watts
NG Fuel Consumption @ 50% Load
805.4 ft³/hr
NG Fuel Consumption @ 100% Load
1317.7 ft³/hr
LP Fuel Consumption @ 50% Load
8.57 gallons/hr
LP Fuel Consumption @ 100% Load
14.25 gallons/hr
Rated Amps
417 Amps
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
71 dbA
Transfer Switch
Automatic (Not Included)
Battery
Not Included (550 CCA)
Enclosure
Aluminum
Mounting Pad
Concrete (Not Included)
Cooling System
Liquid Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Cummins Onan
Starting System
12v Auto Start
CC
5900 CC
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
