Cummins RS22 Quiet Connect™ Series 22kW Standby Power Generator

Model:

QC22

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
Cummins RS22 Quiet Connect™ Series 22kW Standby Power Generator
Cummins RS22 Quiet Connect™ Series 22kW Standby Power Generator
Model: QC22
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Electric Generators Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Emergency

Style

Standby (Liquid Cooled)

Run Watts

22,000 Rated Watts

Surge Watts

22,000
Starting Watts

Fuel

LP/Natural Gas

Engine

Cummins Onan

  • Cummins Quiet Connect™ Series 22kW Premium Grade Generator
  • Great for home & light commercial applications
  • Powerd By Cummins 2.4L Liquid-Cooled Engine
  • 1800 RPM design provides reliability and fuel efficiency
  • Brushless CA Series Alternator
  • Provides +/- 1% voltage & +/- 0.25% frequency regulation
  • As close to utility power as you can get in a standby generator
  • Advanced Design Sound Attenuated Aluminum Enclosure
  • Aesthetically appealing withstands winds up to 150 MPH
  • One of the quietest generators of its kind (64dB @ 7M)
  • PowerCommand® Electronic Control
  • Provides industry-leading self-diagnostic capabilities
  • Flexible Exercise Mode
  • Exercise at a time, frequency and duration that suits you
  • Reducing unnecessary fuel consumption, emissions and noise
  • Designed For Extreme Environmental Conditions
  • Allows for cold weather starts down to -40 °F
  • Automatic Transfer Switch (Sold Separately)
  • Fork Lift or Loading Dock is Required for Delivery
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer, and Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

QC22
specs product image PID-13194
Overview
Weight
1070 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Style
Standby Generator
Product Length
72 Inches
Product Width
34 Inches
Product Height
45.5 Inches
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
22000 Watts
Surge Watts
22000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
22000 Watts
LP Power Capacity
22000 Watts
NG Fuel Consumption @ 50% Load
173 ft³/hr
NG Fuel Consumption @ 100% Load
278.8 ft³/hr
LP Fuel Consumption @ 50% Load
2 gallons/hr
LP Fuel Consumption @ 100% Load
3.1 gallons/hr
Rated Amps
92 Amps
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
64 dbA
Transfer Switch
Automatic (Not Included)
Battery
Not Included (550 CCA)
Enclosure
Aluminum
Mounting Pad
Concrete (Not Included)
Cooling System
Liquid Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Cummins Onan
CC
2400 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
