Cummins RS36 Quiet Connect™ Series 36kW Standby Power Generator (277/480V 3-Phase)

Model:

RS36-480V

Write A Review
$17,259.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
This Item Is Built To Order
synchrony card logo
$303 / Month
With our 82 months 10.99% APR*
82 fixed monthly payments required.
Cummins RS36 Quiet Connect™ Series 36kW Standby Power Generator (277/480V 3-Phase)
Cummins RS36 Quiet Connect™ Series 36kW Standby Power Generator (277/480V 3-Phase)
Model: RS36-480V
$17,259.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Electric Generators Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Emergency

Style

Standby (Liquid Cooled)

Run Watts

36,000 Rated Watts

Surge Watts

36,000
Starting Watts

Fuel

LP/Natural Gas

Engine

Cummins Onan

    ^Please Note - Requires Loading Dock or Forklift For Delivery^
  • Cummins Quiet Connect
  • For light commercial applications w/ 277/480V 3-Phase power
  • Powerd By Cummins 2.4L Turbocharged Liquid-Cooled Engine
  • 1800 RPM design provides reliability and fuel efficiency
  • Brushless CA Series Alternator
  • Provides +/- 1% voltage & +/- 0.25% frequency regulation
  • As close to utility power as you can get in a standby generator
  • Advanced Design Sound Attenuated Aluminum Enclosure
  • Aesthetically appealing withstands winds up to 150 MPH
  • One of the quietest generators of its kind (63dB @ 7M)
  • PowerCommand® Electronic Control
  • Provides industry-leading self-diagnostic capabilities
  • Flexible Exercise Mode
  • Exercise at a time, frequency and duration that suits you
  • Reducing unnecessary fuel consumption, emissions and noise
  • Coolant Heater For Extreme Environmental Conditions (Included)
  • Factory installed, Allows for cold weather starts down to -40 °F
  • Automatic Transfer Switch (Sold Separately)
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer, and Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

RS36-480V
specs product image PID-160287
General Information
Product Category
Generator - Standby
Overview
Product Category
Generator - Standby
Weight
1294 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Style
Standby Generator
Product Length
94 Inches
Product Width
34 Inches
Product Height
45.5 Inches
Product Specs
Voltage
277/480 Three-Phase
Frequency
60 Hertz
Alternator
Brushless
Rated Watts
36000 Watts
Surge Watts
36000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
36000 Watts
LP Power Capacity
36000 Watts
NG Fuel Consumption @ 50% Load
292.3 ft³/hr
NG Fuel Consumption @ 100% Load
472.3 ft³/hr
LP Fuel Consumption @ 50% Load
3.2 gallons/hr
LP Fuel Consumption @ 100% Load
5.1 gallons/hr
Rated Amps
54.1 Amps
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
63 dbA
Transfer Switch
Automatic (Not Included)
Battery
Not Included (550 CCA)
Enclosure
Aluminum
Circuit Breaker Size
60 Amps
Mounting Pad
Concrete (Not Included)
Cooling System
Liquid Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Cummins Onan
Starting System
12v Auto Start
CC
2400 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
