Generac XC6500 - 6500 Watt Professional Portable Generator (49-State)

Model:

6823

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Generac XC6500 - 6500 Watt Professional Portable Generator (49-State)
Generac XC6500 - 6500 Watt Professional Portable Generator (49-State)
Model: 6823
Was $2,999.00
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Electric Generators Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Professional

Style

Portable

Run Watts

6,500 Rated Watts

Surge Watts

8,125
Starting Watts

Fuel

Gasoline

Engine

Generac OHVI



Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
  • Generac® XC6500 - XC Series Professional Series Portable Generator (49 State / CSA)
  • Engineered specifically for contractors and job sites
  • TruePower™ Technology - Less Than 5% THD
  • Provides clean, smooth operation of sensitive tools and power equipment
  • 426cc Generac G-Force Engine - Designed Specifically For Generators
  • Provides longer life and longer maintenance intervals
  • Full Pressure Lubrication System w/ Oil Filter & Low Oil Shutdown
  • Provides maximum safety for longer engine life
  • 8.5-Gallon, Impact Resistant Fuel Tank w/ Fuel Gauge & Fuel Shut-Off
  • Provides up to 14 hours of run time @ 1/2 load
  • Recessed design helps protect tank during forklift transportation
  • Full Panel GFCI Protection - OSHA Compliant
  • Requires GFI type manual transfer switch for panel connection; Not compatible w/ Interlock Kits
  • Covered outlets provided added protection from rain and snow
  • Heavy-Duty, 12-Gauge Steel Tube, Fully Wrapped X-Frame
  • Keeps the generator and fuel tank protected from damage
  • Built-In steel lifting pocket provides a lifting point for forklifts and cranes
  • Fold-Down, Locking Dual Handle Design
  • One-handed locking design allows for easier transportation and storage
  • Protected Axle w/ 10" Never Flat Wheels and Steel Hubs
  • Robust design, integrated into frame for added protection
  • Reinforced, welded steel feet provide added stability and longevity
  • Oversized, Glove-Ready Touchpoints
  • Never have to remove your gloves to operate rocker switches, choke lever & fuel shut-off
  • Standard Engraving Plate
  • Makes it easy for gen to be tagged for contractor and rental fleets
  • Hour Meter & Easy-Access Routine Maintenance Points
  • Provides easy access to spark plug and oil filter
  • Includes Maintenance Kit
  • 3-Year Limited Residential & 2-Year Limited Commercial Warranty - Non-CARB Compliant - Not For Sale In California
California residents see
Warning: This product can expose you to chemicals including Carbon monoxide which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

Plug Types
NEMA 5-20R (Wall-Type)
NEMA 5-20R (Wall-Type)
NEMA L5-30R
NEMA L14-30R
6823
specs product image PID-77091
Overview
Assembly Required
Yes
Weight
243 Pounds
Consumer Warranty
3 Years
Commercial Warranty
2 Years
Product Style
Portable Generator
Product Length
34.3 Inches
Product Width
28.6 Inches
Product Height
32.5 Inches
UPC
696471070903
Additional Model Numbers

6823-0, 6823

Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Auto Voltage Regulation
Yes
Rated Watts
6500 Watts
Surge Watts
8125 Watts
Fuel Type
Gasoline
Rated Amps
27 Amps
Portability Kit
Never Flat Wheels
Tank Size
8.5 Gallons
Run Time @ 50% Load
14 Hours
Fuel Gauge
Yes
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
Not Measured by Manufacturer
Idle Control
No
Hour Meter
Yes
Voltage Meter
No
Lifting Eye
Yes
Grade Type
Professional
Engine
Engine Brand
Generac OHVI
Starting System
Recoil Start
CC
426 CC
Consumer Engine Warranty
3 Years
Commercial Engine Warranty
2 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Plugs
NEMA 5-20R - Wall-Type
2
NEMA L5-30R
1
NEMA L14-30R
1
