Features
Grade
Emergency
Style
Standby (Air Cooled)
Run Watts
16,000 Rated Watts
Voltage
120/240 Single-Phase
Fuel
LP/Natural Gas
Engine
Generac
- 100-Amp Automatic Transfer Switch w/ 16 Circuits included
- Pre-wired External Connection Box
- 30' Pre-Wired Conduit From Transfer Switch To Generator
- 2' Pre-Wired Conduit From Transfer Switch To Main Panel
- Composite Mounting Pad
- Emergency Standby Power Generator
- Designed for homes
- Runs off natural gas or LP fuel source
- Sound level comparable to an idling car
- Runs at a quiet 66 decibels at 23 feet
- Generac OHVI Air-Cooled Engine
- Maximizes engine "breathing" for increased fuel efficiency
- Automatic Exerciser
- Allows generator to run a self-test every 7 days
- Weather Protected Steel Enclosure
- Shelters generator from weather and reduces exterior noise
- Two Line LCD Digital Controller
- Allows for simple user interface for ease of operation
- Built-in Battery Charger
- Battery Sold Separately
Specifications
5243
Overview
Weight
445 Pounds
Made in USA
Yes
Consumer Warranty
3 Years
Commercial Warranty
3 Years
Product Style
Standby Generator
Product Length
48 Inches
Product Width
24 Inches
Product Height
28.25 Inches
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
16000 Watts
Surge Watts
16000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
15000 Watts
LP Power Capacity
16000 Watts
NG Fuel Consumption @ 50% Load
245 ft³/hr
LP Fuel Consumption @ 50% Load
2.51 gallons/hr
Rated Amps
67 Amps
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
71.5 dbA
Transfer Switch
Automatic (Included)
Transfer Switch Amperage
100-Amps
Max Circuits
16
Battery
Not Included (525 CCA)
Enclosure
Steel
A/C Ton Rating
5-Tons
Mounting Pad
Composite (Included)
Transfer Switch Style
Pre-Wired (16-Circuit)
ATS Poles
2 Poles
Cooling System
Air Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Generac
HP
30 HP
CC
992 CC
Consumer Engine Warranty
3 Years
Commercial Engine Warranty
3 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Transfer Switch Circuits
15A 120V
5
20A 120V
5
20A 240V
1
40A 240V
1
50A 240V
1
Reviews
(10)
Generac Guardian 5243 Reviews & Ratings
How-To Articles
How to Pick the Perfect Home Standby Generator
With increasing power outages, pandemic shutdowns, and social unrest sweeping t...
How to Find An In-Stock Generator During a Blackout
Finding an electric generator can be a challenge at times, especially during a ...
How to Size a Home Standby Generator
Put down the calculator! Sizing an essential circuit standby generator is extre...
Manuals
5243
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
Guardian 16 kW Emergency Power System w/ Steel Enclosure
