Generac Guardian Series™ 5875 - 20kW Smart Circuit Standby Generator System (Alum) (Scratch &Dent)

Model:

5875-SD

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Generac Guardian Series™ 5875 - 20kW Smart Circuit Standby Generator System (Alum) (Scratch &Dent)
Generac Guardian Series™ 5875 - 20kW Smart Circuit Standby Generator System (Alum) (Scratch &Dent)
Model: 5875-SD
Was $4,497.00
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Electric Generators Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Emergency

Style

Standby (Air Cooled)

Run Watts

20,000 Rated Watts

Voltage

120/240 Single-Phase

Fuel

LP/Natural Gas

Engine

Generac

  • ***Scratch & Dent*** - Cosmetic Damage
  • Side panel has been replaced - may have minor scrathes/scuffs
  • Smart Circuit Standby Generator System
  • Restores power to your entire electrical panel automatically
  • Digital Load Management (DLM) protects against overload
  • Nexus Smart Switch™ (RTSD200A3)
  • Built-in DLM safely alternates 2 x 5-ton central air conditioners
  • Service Rated: Mounts between meter and main service panel
  • 200-amp aluminum indoor/outdoor (NEMA 3R) cabinet
  • Nexus™ Digital Controller
  • Provides system status to compatible Nexus™ wireless monitors
  • Aluminum Sound-Attenuated Enclosure
  • Weather-proof design significantly slows corrosion
  • Reduces sound pressure to a low 66 dB(A)
  • Automatic Voltage Regulator
  • Generates clean electricity (+/- 1% regulation)
  • Safe for sensitive electronics like computers and televisions
  • Generac OHVI Air-Cooled Engine
  • Full pressure lubrication system w/ 2 year oil change interval
  • Also Included: Facia Skirting Kit & 1' Flexible Fuel Line

Specifications

5875-SD
specs product image PID-6123
Overview
Weight
541 Pounds
Made in USA
Yes
Consumer Warranty
3 Years
Commercial Warranty
3 Years
Product Style
Standby Generator
Product Length
48 Inches
Product Width
25 Inches
Product Height
29 Inches
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
20000 Watts
Surge Watts
20000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
18000 Watts
LP Power Capacity
20000 Watts
NG Fuel Consumption @ 50% Load
206 ft³/hr
LP Fuel Consumption @ 50% Load
1.89 gallons/hr
Rated Amps
83 Amps
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
66 dbA
Transfer Switch
Automatic (Included)
Transfer Switch Amperage
200-Amps
Battery
Not Included (525 CCA)
Enclosure
Aluminum
A/C Ton Rating
2 x 5-Tons
Transfer Switch Style
Service Disconnect
ATS Poles
2 Poles
Cooling System
Air Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Generac
CC
999 CC
Consumer Engine Warranty
3 Years
Commercial Engine Warranty
3 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
