Generac MLT4150M-STD - 15kW Towable Diesel Horizontal Mast Light Tower w/ Mitsubishi Engine & Manual Winch

Model:

MLT4150M-STD

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Generac MLT4150M-STD - 15kW Towable Diesel Horizontal Mast Light Tower w/ Mitsubishi Engine & Manual Winch
Generac MLT4150M-STD - 15kW Towable Diesel Horizontal Mast Light Tower w/ Mitsubishi Engine & Manual Winch
Model: MLT4150M-STD
Product Discontinued
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Features

Grade

Professional

Style

Tow-Behind

Run Watts

15,000 Rated Watts

Voltage

120/240 Single-Phase

Fuel

Diesel

Engine

Mitsubishi

  • MLT4150M-STD - 16kW Horizontal Mast Light Tower (Mitsubishi® / Manual Winch)
  • Designed & engineered for optimum performance, reliability and longevity
  • 4 x 1000-Watt Metal Halide Lamps
  • Provides light coverage for up to 7 acres; Individual On/Off switches
  • Oval aluminum reflectors w/ tempered glass lens & silicone gaskets
  • Friction disc mounting for tool less positioning
  • 30-Foot, 3-Section Horizontal Mast w/ Manual Winch
  • Dual-Winch system located at ergonomic height; Simple, single person operation
  • 359° Ground-Level mast/fixture rotation w/ locking system
  • 1.76L Mitsubishi® S4L2 Liquid Cooled Diesel Engine (EPA Tier 4 Final)
  • Fuel efficient design runs at 1800 RPM for extended engine life
  • 56-Gallon Polyethylene Internal Fuel Tank
  • Provides up to 43 hours of run time with all 4-lights On
  • 120/240V - 125/63A Marathon Electric Brushless Alternator
  • Robust design provides up to 15 kW of standby output
  • (2) 240V 30A (L6-30R) & (2) 240V 50A (Non-Nema 6369) Twistlock Outlets
  • Individually breakered for added safety during operation
  • (2) 120V 20A GFCI Duplex Outlets
  • Provides the convenience of powering 120V equipment
  • 14-Gauge Steel Enclosure - 68 dB(A) @ 23'
  • Powder-coated, UV and fade resistant paint for exterior/interior of enclosure
  • Multi-lingual operating/safety decals; Manual holder w/ operating manual
  • Tubular Steel Trailer w/ 48" Removable Tongue
  • (4) 2000 lb. Adjustable leveling jacks; Transport/lock in horizontal storage position
  • Front step platform for easy adjustment of light fixtures
  • DOT Approved Tail, Side, Brake and Directional Lights
  • 3000 lb. Leaf spring axle; Single wall polyethylene fenders
  • 15" P205/75R15 - 6 ply wheel/tire; 58" Axle Span
  • 2" Ball hitch & safety chains w/ spring loaded safety hooks
  • Includes Starting Battery
  • CUSTOMERS MUST UNLOAD FROM FREIGHT CARRIER
  • 1-Year / Unlimited, 2-Year/ 2,000 Hour Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Carbon monoxide which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

Plug Types
NEMA L6-30R
NEMA L6-30R
NEMA 5-20R Single (Wall-Type)
NEMA 5-20R Single (Wall-Type)
MLT4150M-STD
specs product image PID-76323
Overview
Weight
2015 Pounds
Certification
EPA Tier 4
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Style
Light Tower
Product Length
170 Inches
Product Width
68 Inches
Product Height
70 Inches
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Rated Watts
15000 Watts
Fuel Type
Diesel
Rated Amps
125/63 Amps
Tank Size
56 Gallons
Fuel Tank Material
Plastic
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
68
Idle Control
No
Hour Meter
Yes
Lifting Eye
Yes
Battery
Included
Grade Type
Professional
Engine
Engine Brand
Mitsubishi
Starting System
12-Volt Button Start
HP
24.7 HP
CC
1760 CC
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Plugs
NEMA 5-20R - Single - Wall-Type
2
NEMA L6-30R
2
CS6364/5 - 50-Amp Twistlock
2
