Generac RXG16EZA1W
Generac RXG16EZA1W
Hover to zoom
1 of 1

Generac 100-Amp Indoor Automatic Transfer Switch w/ 16-Circuit Load Center

Model:

RXG16EZA1W

Write A Review
$919.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships Today, April 1st
Shipping to60601
synchrony card logo
$154 / Month
Suggested monthly payments with 6 month financing.
Generac 100-Amp Indoor Automatic Transfer Switch w/ 16-Circuit Load Center
Generac 100-Amp Indoor Automatic Transfer Switch w/ 16-Circuit Load Center
Model: RXG16EZA1W
$919.00
Accessories
Features
Specifications
Reviews
How-To Articles

Recommended Accessories

Electric Generators Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Type

Load Center

Amp Rating

100

Circuits

16

Voltage

120/240 Single-Phase

Enclosure

NEMA 1R

  • 100-A Indoor Automatic Transfer Switch w/ 16-Circuit Load Center
  • Perfect for backing up emergency circuits
  • Steel NEMA-1 Indoor Enclosure
  • Electrostatically applied and baked powder paint
  • Breakers:
  • 5 x 15A (120V) 1-Pole
  • 5 x 20A (120V) 1-Pole
  • 1 x 20A (240V) 2-Pole
  • 1 x 40A (240V) 2-Pole
  • 1 x 50A (240V) 2-Pole
  • Recommended Generator Size Range 11kW - 16kW
  • For Use With Generac Automatic Standby Generators Only
California residents see
Warning: This product can expose you to chemicals including Di-n-butyl phthalate (DBP) which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

RXG16EZA1W
specs product image PID-123379
Overview
Weight
30 Pounds
Consumer Warranty
5 Years
Product Length
27 Inches
Product Width
13 Inches
Product Height
7 Inches
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Amps
100 Amps
Transfer Switch Amperage
100-Amps
Enclosure
NEMA 1R
Number of Circuit Breakers
16
Max Generator Input
100 Amps
Maximum Wattage
24000 Watts
Transfer Switch Circuits
15A 120V
5
20A 120V
5
20A 240V
1
40A 240V
1
50A 240V
1
Circuit Breaker Protection
Each Circuit

Reviews

(2)
Generac RXG16EZA1W Reviews & Ratings
Verified Buyer
Verified Buyer
Nice Transfer Switch
By Todd F
New Jersey
Purchased 02/01/2024 |
Review Posted 02/23/2024
Overall this is a nice produce. I wish generac offered more interior rated transfer switches. Its annoying surface mounting the exterior rated transfer switches inside. Only thing to be aware of with this is the depth of the enclosure will fit in a 2x6 wall not a 2x4 wall. If installed in a 2x4 wall it will stick out of the wall a couple inches and not fully be flushmount. You'll have to packout around the enclosure or add trim to make it look right
Todd F Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
4/5
icon-review-marker
Pros:
Easy To Use
Cons:
Big
Verified Buyer
Verified Buyer
Great Alternative To A Whole House System
By Frank C
Pennsylvania
Purchased 02/10/2023 |
Review Posted 03/07/2023
I couldn't use a whole house system without remodeling a beautifully built panel concealment cabinet. This just fit in the space and got me out of a jam. It powers enough to keep the customer comfortable year round. Be careful, space is rather tight pulling Generac wire in thru the supplied feed knockout. Be forewarned that you may also need to add a neutral lug to the bar for a #2 or #4 feed from the generator. A #6 neutral feed will fit the buss as is.
Frank C Recommends This
Was this review helpful?
Manufacturer Response
Thank you for taking time out of your day to provide us with your valuable feedback. If you run into any questions, please give us a call at 888-436-3722!
Generac
Rating Breakdown
Features
5/5
icon-review-marker
Quality
4/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Pros:
Easy To Use, I'd Buy It Again
Cons:
Minor design problems
