Features
Grade
Professional
Style
PTO
Run Watts
10,000 Rated Watts
Voltage
120/240 Single-Phase
- Convert Your Tractor Into a Generator
- Use your compact tractor engine to generate electricity
- Requires 20-HP at the PTO to operate properly
- Multiple Applications
- Generate electricity to power tools on the farm or ranch
- Backup your home, barn or buildings during a power outage
- Brushless Alternator
- Produces clean and safe electricity for sensitive electronics
- Low harmonic content (<5%)
- Mainline Circuit Breaker
- Protects generator and appliances from overload
- Large Voltmeter
- Easily monitor your power usage right from your tractor seat
- Cast Iron Gear Case
- Rugged, high-quality material designed to weather the outdoors
- 1-3/8" Six Spline
- Connect tumbling bar (sold separately) between tractor and PTO
- Mobility (Sold Separately)
- Transport your PTO generator with a trailer or 3-point hitch
- TDM76 - Trailer *Requires SA11310 tumbling bar (Sold Separately)
- TPH250 - 3-Point hitch *Requires 300228 tumbling bar (Sold Separately)
- Full power 60A plug ships with the generator
California residents see
Warning: This product can expose you to chemicals including Benzene which is known to the State of California to cause Cancer, and Ethylene glycol (ingested) which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
Plug Types
99840-003
General Information
Product Category
Generator - PTO
Overview
Product Category
Generator - PTO
Weight
166 Pounds
Consumer Warranty
1 Year
Product Style
PTO Generator
Product Length
33 Inches
Product Width
19 Inches
Product Height
20.2 Inches
Additional Model Numbers
W10PTOS, 99840-003
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
No
Rated Watts
10000 Watts
Rated Amps
42 Amps
Voltage Meter
Yes
Tractors HP
20 HP
PTO RPMs
515 RPM
Grade Type
Professional
Plugs
NEMA 5-20R - Wall-Type
1
NEMA 14-60R
1
Reviews
(17)
Winco 99840-003 Reviews & Ratings
Product Q&A
(2)
Product Questions
Answered by Jared, the Generator Expert
Will the W10PTOS work with my Kubota B2370 (rated for 17HP at rear PTO)?
Al
from New Jersey
December 18, 2016
With most 10kW and 15kW PTO driven generators driven at 540 RPM PTO and the Winco 10 and 15kW units driven at 515 RPM PTO, does that mean I could run my Kubota 38 h.p. at a lower RPM for the Winco to operate at full capacity or would my Kubota still have to still run at about the same RPM's as the 540 RPM PTO generators? What would be the difference in the rpm's between the two with my tractor for them to maintain the same load?
Jeff
from Georgia
December 09, 2013
