Model: RDT-CFNC-200ASEQS4
Service Disconnect
$1,380.00
In-Stock
$120.99
In-Stock
Features
Type
Standard
Amp Rating
Load Mgmt.
Voltage
120/240 Single-Phase
Enclosure
NEMA 1R
- Standard Features
- UL listed and CSA certified
- Two-pole, single-phase, open-transition transfer switch
- Double throw inherently interlocked design
- Solid Neutral
- 220/240 VAC, 50/60 Hz (jumper)
- Contractor manually operable for maintenance purposes
- NEMA 1 (indoor) enclosure
- MPAC™ 500 Controller Features
- User-friendly interface and easy-to-find international symbols
- LED indication of system faults
- Test button (with or without load)
- Exercise set button
- Single-phase voltage sensing on both sources
- Line-to-line frequency sensing
- Fixed time delays
- 5-year limited warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
RDT-CFNA-0200A-QS5
General Information
Product Category
Generator Transfer Switches
Overview
Product Category
Generator Transfer Switches
Weight
15 Pounds
Consumer Warranty
5 Years
Product Depth
7 Inches
Product Width
13.4 Inches
Product Height
24.1 Inches
Additional Model Numbers
RDT-CFNA-0200A, RDT-CFNA-0200A-QS5
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Enclosure
NEMA 1R
Transfer Switch Style
Standard Installation
ATS Poles
2 Poles
Max Utility Input
200 Amps
Max Generator Input
200 Amps
UL Listed
Yes
Reviews
(1)
Kohler RDT-CFNA-0200A-QS5 Reviews & Ratings
Kohler 35 RES
By Stephen Jackson
Addis, Louisiana
Review Posted 03/09/2010
I selected the 30RES but I really have a 35RES model. Right after power was restored following hurricane Gustav, I looked at generator sets.
I liked the Kohler 35RES because it had a GM V-6 engine without a timing belt. The engine runs at 1800 rpm which saves wear and tear plus fuel.
I have the RDT 200 amp automatic transfer switch. The system was installed 12/23/2008. The first time that it ran in the automatic mode was about six months after it had been installed. I came home to find the clocks blinking but the lights on.
The genset is so quiet that I did not hear it running when I arrived. The transfer switch had detected the power loss, started the generator, and transferred the load without a problem.
The neighbors who had laughed and snickered at me were out on their patios trying to stay cool while I was in the AC. I had set the transfer switch to exercise the generator on Sunday mornings at 0900 hrs.
You have to go out the first time that you want to set the exercise time and manually press the exerciser button. Press it for a short time (3 seconds) and only the generator starts and runs for the 20 minute time. Press and hold the exerciser button until you hear the switch transfer the load and it will start the generator and transfer the load to the genset.
This is so quick you barely see a blink in the lights. This is the mode that I use. Once you have set the exerciser, you don't have to do anything with it again unless you want to change the time which it exercises in which case you do the above at the time you want the genset to exercise.
This is a very simple, easy to use transfer switch. All of the settings are done at the factory so you don't have to worry with engine start delay, transfer delay, and so on.
The fuel for the genset is natural gas as I really did not want a tank to store fuel. I do have the accessory to change to propane and some parts set up for this if I need to, but natural gas works great.
One thing that I will say that the owner needs to do is about once a month check the oil, and the water level in the battery. Other than that, do the PM and it should last many, many years.
I liked the Kohler 35RES because it had a GM V-6 engine without a timing belt. The engine runs at 1800 rpm which saves wear and tear plus fuel.
I have the RDT 200 amp automatic transfer switch. The system was installed 12/23/2008. The first time that it ran in the automatic mode was about six months after it had been installed. I came home to find the clocks blinking but the lights on.
The genset is so quiet that I did not hear it running when I arrived. The transfer switch had detected the power loss, started the generator, and transferred the load without a problem.
The neighbors who had laughed and snickered at me were out on their patios trying to stay cool while I was in the AC. I had set the transfer switch to exercise the generator on Sunday mornings at 0900 hrs.
You have to go out the first time that you want to set the exercise time and manually press the exerciser button. Press it for a short time (3 seconds) and only the generator starts and runs for the 20 minute time. Press and hold the exerciser button until you hear the switch transfer the load and it will start the generator and transfer the load to the genset.
This is so quick you barely see a blink in the lights. This is the mode that I use. Once you have set the exerciser, you don't have to do anything with it again unless you want to change the time which it exercises in which case you do the above at the time you want the genset to exercise.
This is a very simple, easy to use transfer switch. All of the settings are done at the factory so you don't have to worry with engine start delay, transfer delay, and so on.
The fuel for the genset is natural gas as I really did not want a tank to store fuel. I do have the accessory to change to propane and some parts set up for this if I need to, but natural gas works great.
One thing that I will say that the owner needs to do is about once a month check the oil, and the water level in the battery. Other than that, do the PM and it should last many, many years.
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Product Q&A
(1)
Product Questions
Answered by Jared, the Generator Expert
Can we use a Kohler RDT-CFNA-0200A with a Kohler RESA20kw generator ?
Joe Dibartolomeo
from New York
September 30, 2013
How-To Articles
How to Avoid Tripping a Generator With a Bonded Neutral
Does your generator outlet trip every time you connect it to your home's transf...
How to Pick the Perfect Manual Transfer Switch
During a sudden power outage, you probably don’t feel like running multip...
Electric Generators How-To Library
Articles, Tips and Buying Guides from Our Experts
Manuals
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
Kohler RDT Series 200-Amp Indoor Automatic Transfer Switch
