Voltmaster XCR105EH - 9500 Watt Electric Start Professional Generator w/ Honda GX Engine

Model:

XCR105EH

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Voltmaster XCR105EH - 9500 Watt Electric Start Professional Generator w/ Honda GX Engine
Voltmaster XCR105EH - 9500 Watt Electric Start Professional Generator w/ Honda GX Engine
Model: XCR105EH
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Electric Generators Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Professional

Style

Portable

Run Watts

9,500 Rated Watts

Surge Watts

10,000
Starting Watts

Fuel

Gasoline

Engine

Honda GX

  • Voltmaster XCR Series Contractor/Rental Grade Generator
  • Designed specifically for contractors & jobsite applications
  • OSHA Compliant Total Ground Fault System
  • Provides total 120/240 VAC ground-fault protection on all recps
  • Honda GX630 Industrial-Grade V-Twin Engine w/ Electric Start
  • Quiet operation and greater fuel efficency on the job site
  • Includes battery rack & cables (Battery Sold Separately)
  • Protected By Honda Oil Alert® Warning System
  • Shuts the engine down if oil reaches an unsafe operating level
  • Idle Control & 7.25-Gallon Fuel Tank w/ Fuel Gauge
  • Allows for up to 8 hours of run time @ half load
  • Magnetic CB & Brush Alternator w/ All Copper Windings
  • Provides safer operation & clean power; <6% harmonic distortion
  • Voltmeter & Hour Meter
  • Allows you to easily monitor and maintain your generator
  • Heavy Duty Frame & Modular Design w/ Side Control Panel
  • Provides greater protection for the engine & components
  • Makes it easy to operate when truck mounted
  • ***Not For Use w/ Transfer Switches or Interlock Kits***
  • 1-Year Consumer/30-Day Commercial Warranty
California residents see
Warning: This product can expose you to chemicals including Gasoline engine exhaust (condensates/extracts) which is known to the State of California to cause Cancer
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

Plug Types
NEMA 5-20R (GFCI)
NEMA 5-20R (GFCI)
NEMA L5-30R
NEMA L14-30R
XCR105EH
specs product image PID-17534
Overview
Weight
297 Pounds
Made in USA
Yes
Consumer Warranty
1 Year
Commercial Warranty
30 Days
Product Style
Portable Generator
Product Length
37.25 Inches
Product Width
23.5 Inches
Product Height
26 Inches
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Rated Watts
9500 Watts
Surge Watts
10000 Watts
Fuel Type
Gasoline
Rated Amps
40 Amps
Portability Kit
Sold Separately
Tank Size
7.25 Gallons
Run Time @ 50% Load
8 Hours
Fuel Tank Material
Metal
Fuel Gauge
Yes
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
Not Measured by Manufacturer
Idle Control
Yes
Hour Meter
Yes
Voltage Meter
Yes
Lifting Eye
Yes
Neutral Type
Bonded
Battery
Not Included
Grade Type
Professional
Engine
Engine Brand
Honda GX
Starting System
12-Volt Key Start
HP
20 HP
CC
688 CC
Consumer Engine Warranty
3 Years
Commercial Engine Warranty
3 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Plugs
NEMA 5-20R - GFCI
2
NEMA L5-30R
1
NEMA L14-30R
1
CS6364/5 - 50-Amp Twistlock
1
